Equipped with BIPOD sorting grippers, offering a powerful maximum gripof 240kg and precise handling of 1-25 mm plates, reducing unloadingtime by 60%!
One-click start and fully automated task execution,effectively saving 3-4 operators and reducing laborcosts by 80%!
Seamless integration with factory ERP, MES, and AGVsystems for production task management, real-timemonitoring, and automatic reporting.
The machine is equipped with a complete software suite, covering nesting.material warehouse management, cutting execution, sorting, stacking andintelligent master control, forming a fully integrated system.
4-15 levels (adjustable according to customer requirements)
Maximum load capacity per cargo space: 5 tons
Allowable stacking sheet size: 3000mmx1500mm, 4000mmx2000mm, 6000mmx2500mm
Servo-driven system with positioning accuracy of +0.5 mm
High-density vacuum matrix suction cups, providing full coverage of the gripping area
Automatic sheet separation and cornering device
Single-sheet detection device
Power-off and air-off anti-fall function
Maximum gripping force: 240Kg
Positioning accuracy: +0.5mm
Maximum gripping size: 2500mmx1000mm
Minimum gripping size: 150mmx150mm
Multi-axis linkage for fast and efficient operation
Automatically generates gripper pick-up positions
Automatic planning of gripper sorting paths
Automatic generation of stacking position data
Model | GH3015 | GH4020 | GH6015 |
|---|---|---|---|
Carbon steel sorted sheet thickness | 1-14mm | 1-16mm | 1-25mm |
Load-unload manipulator type | Standalone type | Composite type | Composite type |
Max adsorption weight of load-unload manipulator | 500KG | 1000KG | 2000KG |
Octopus gripper selection: M002B2510(Standard) | Max grab size: 2500mm*1000mm Min grab size: 150mm*150mm Max grabbing weight: 240KG | Max grab size: 2500mm*1000mm Min grab size: 150mm*150mm Max grabbing weight: 240KG | Max grab size: 2500mm*1000mm Min grab size: 150mm*150mm Max grabbing weight: 240KG |
Stereo warehouse layers | 10 (adjustable per customer) | 10 (adjustable per customer) | 10 (adjustable per customer) |
Max net load per stereo warehouse layer | 3000KG | 5000KG | 5000KG |
Min allowable stacking size (stereo warehouse) | 3000*1500mm | 4000*2000mm | 6000*2500mm |
Min allowable stacking size (stereo warehouse) | 1250*1250mm | 1250*1250mm | 1250*1250mm |
